Ubiquiti UP-Chime-EU WiFi Smart Chime
Ubiquiti UP-Chime-EU WiFi Smart Chime
Product Code:
Availability:
Availability:
Ubiquiti UP-Chime-EU
Out Of Stock
Out Of Stock
Plug-in chime designed to pair with a UniFi doorbell.
Note. EU power plug only.
Third-party WiFi configuration available during setup with the UniFi Protect mobile app.
Compatibility
UVC-G4 Doorbell Pro PoE Kit
UA-G2-Pro
UVC-G4 Doorbell Pro
UA-G2-SK-Pro
UVC-G4-DoorBell
UA-G3-Pro
UA-Intercom
UA-G3-SK-Pro
UA-G3-Intercom
| UniFi Chime | |
|---|---|
| Mechanical | |
| Dimensions | US: 62 x 50.6 mm (2.4 x 2") EU: 62 x 68.3 mm (2.4 x 2.7") (Without prong) |
| Enclosure Material | Polycarbonate, fabric |
| System | |
| Networking Interface | WiFi 802.11 b/g/n |
| Power Method | AC |
| Supported Voltage Range | 100–240V, 50/60 Hz |
| Max. Power Consumption | 3.7W |
| Antenna Gain | 2 dBi |
| ESD/EMP Protection | Air: +16kV, Contact: +8kV |
| LEDs | (5) White |
| Button | Factory reset |
| Ambient Operating Temperature | 0 to 40 C (32 to 104 F) |
| Ambient Operating Humidity | 10 to 90% noncondensing |
| Certifications | FCC, IC, CE |
| Audio | |
| Speaker | Yes |
| Buzzer | Yes |
| Software | |
| Web Application | UniFi Protect: Version 2.0 and later |
| Mobile Apps |
UniFi Protect iOS: Version 1.6.2 and later UniFi Protect Android: Version 1.6.0 and later |
