Ubiquiti PoE Over 2-Wire Retrofit Extender - UACC-Retrofit-PoE-2Wire
Ubiquiti PoE Over 2-Wire Retrofit Extender - UACC-Retrofit-PoE-2Wire
Product Code:
Availability:
Availability:
Ubiquiti UACC-Retrofit-PoE-2Wire
Out Of Stock
Out Of Stock
A pair of extenders that extends PoE over twisted-pair or coaxial cables, ideal for retrofit scenarios.
#1: Transmitter
(1) PoE++ input
(1) 2-wire output
(1) 2-wire to BNC adapter
#2: Receiver
(1) PoE/PoE+ output
(1) 2-wire input
(1) 2-wire to BNC adapter
Buy Ubiquiti UACC-Retrofit-PoE-2Wire PoE Over 2-Wire Retrofit Extender
Dimensions PoE in/out: 40 x 105 x 25 mm (1.6 x 4.1 x 1")
Adapter: 43.5 x 138 x 30 mm (1.7 x 5.4 x 1.2")
Weight PoE in: 77 g (2.7 oz)
PoE out: 79 g (2.8 oz)
Adapter: 140 g (4.9 oz)
Enclosure material Polycarbonate
Mounting material Polycarbonate
Coaxial connector BNC female
Hardware
Networking interface (1) 10/100 MbE
(1) Homeplug AV
Power method PoE++
PoE input (1) PoE++, 50V DC, 1.2A
PoE output (1) PoE+, 48V DC, 0.6A
Max. power consumption 3W (Without PoE output)
ESD/EMP protection Air: +8kV, contact: +4kV
Recommend max. cable length UTP 24AWG 0.18ohm/meter RG-6, 0.14ohm/meter
Cable length Bandwidth(Mbps) Max output(W) Bandwidth (Mbps) Max output (W)
50 m 85 25 85 25
100m 85 13 85 20
150m 85 9 85 13
200m 85 6 85 9
250m 80 4 85 7
300m 75 3 85 6
350m 70 0 85 4
400m 65 0 82 3
450m 60 0 80 0
500m 55 0 75 0
550m 50 0 70 0
600m - - 65 0
650m - - 60 0
700m - - 55 0
750m - - 50 0
LED White
Ambient operating temperature -10 to 40 C (14 to 104 F)
Ambient operating humidity 5 to 90% noncondensing
Certifications CE, FCC, IC
