Ubiquiti UVC-AI-Theta-Hub AI Theta Hub
Ubiquiti UVC-AI-Theta-Hub AI Theta Hub
Product Code:
Availability:
Availability:
Ubiquiti UVC-AI-Theta-Hub
In Stock
In Stock
Remote processing hub for any AI Theta deployment, compatible with any AI Theta Lens and AI Theta Audio.
Note. License plate recognition supported with Long-Distance and Wide-Angle lenses.
| UVC-AI-Theta-Hub – Specifications | |
|---|---|
| Mechanical | |
| Dimensions | 140 x 70 x 38 mm (5.5 x 2.8 x 1.5”) |
| Mounting | |
| Wall, ceiling mount (Included) | |
| Performance | |
| Networking Interface |
GbE RJ45 port Theta audio port Theta lens port |
| Video | |
| Image Settings | Color, brightness, sharpness, contrast, white balance, exposure control, 2DNR, 3DNR, NR by motion, masking, text overlay |
| Hardware | |
| Processor | Quad-core Arm Cortex-A53 based chip |
| Enclosure Material | Aluminum alloy |
| Mounting Material | Aluminum alloy |
| Power Method | PoE |
| Supported Voltage Range | 37—57V DC |
| Max. Power Consumption | 12.5W |
| Power Output | 5V DC, 1A per port |
| LCM Display | 0.96" display |
| Button | (1) Factory-reset |
| Environmental | |
| Ambient Operating Temperature | -20 to 40C (-4 to 104F) |
| Ambient Operating Humidity | 10 to 90% noncondensing |
| Compliance | |
| NDAA Compliant | ✓ |
| Certifications | FCC, IC, CE |
